Radar Detectors - An Overview

Radar stands for Radio Detecting And Ranging. The system operates by transmitting radio waves at certain frequencies which reflect off objects and are picked up by the receiver. When the beam reflects off a moving object, a measurable frequency shift occurs which is then converted into miles per-hour to determine the object's speed.

There are 3 main sets of frequencies used by the manufacturers of speed trap equipment. These are known as X, K & KA. The majority of traps use K band (e.g. GATSO cameras and most handheld guns). X band is the oldest and is used by some older gun based systems, it is also the band where most false alarms occur since other pieces of equipment use this frequency range. KA band is used by the new 'Stalker' radar guns and is one of the most popular, having been extended twice since 1991.

GATSO PHOTGRAPHIC TRAPS

GATSO is the name given to the Dutch made "photographic trap" system used in the UK and Europe. The GATSO traps are unmanned and take a photo of the rear of the speeding vehicle. GATSO traps operate on K band and are therefore detectable by most good detectors. The majority of GATSO cameras are inactive - the average ratio is one "live' camera for every ten boxes. Even "inactive" sites will appear to take photographs sing vehicles by flashing at them. but since no photographic equipment is installed no photographs can be taken. If the GATSO system is fully loaded it is transmitting K band signals constantly monitoring the speed of every vehicle that passes.

LASER

The laser speed Detection System uses a gun that emits infrared light pulses just outside the spectrum of visible light. Each pulse measures the distance to any object that reflects the laser. The speed of the object coming towards the gun is measured using a very narrow beam of light so that it can pinpoint a speeding car in the traffic. A radar detector will pick up the signal due to "splattering" caused by the beam hitting warm and cold pockets this "splattering" makes the beam appear much wider.

VG-2 FACTS

VG-2 is a microwave receiver used by some police forces to detect signals radiated by the local oscillator of a radar detector, because of this VG-2 has become known as a 'radar detector' detector. It is primarily used to identify radar detector equipped vehicles, as, in the past drivers faced losing their detector if caught. VG-2 immunity prevents electronic detection of your unit.

VASCAR

VASCAR is an acronym for Visual Average Speed Computer And Recorder. This is little more than a glorified stopwatch, whereby the vehicle is timed over a set distance (for example over two white markings in the road surface or over two bridges) an average speed is then automatically calculated No radio waves or beams of light are emitted and thus this system is unable to be detected by any form of electronic detector.
